12 inch MCZ Chrysochra monocrystalline silicon magnet


Technical performance index

Model: XSMT-0.4T1600S-MCZ

Dimensions: OD2400mm*ID1600mm*H1210mm (total height < 2m)

Weight: ≤10 tons

Number of refrigerating machines: 2

Cooling method: 1) Method 1 (liquid nitrogen precooling + conduction cooling) -- about 12 days

2) Mode 2 (conduction cooling) -- about 18 days

Direction of magnetic field: horizontal

Central magnetic field strength: 0.4T

Excitation demagnetizing time: < 30 minutes

Magnetic leakage field: ≤100Gauss (3 meters away from the center in the X direction)

                                       ≤70Gauss (3 meters from center in Y direction)
