8 "MCZ Chrysochra monocrystalline Silicon magnet


Technical performance index

Model: XSMT-0.3T1420MCZS

Dimensions: OD2160mm*ID1420mm*H1210mm (total height < 1.3m)

Weight: ≤8 tons

Number of refrigerating machines: 2

Cooling method: 1) Method 1 (liquid nitrogen precooling + conduction cooling) -- about 8 days

2) Mode 2 (conduction cooling) -- about 12 days

Number of refrigerating machines: 2

Direction of magnetic field: horizontal

Central magnetic field strength: 0.3T

Excitation demagnetizing time: < 30 minutes

Magnetic leakage field: < 50Gauss (3 meters from the center in the X direction)

                                      < 50Gauss (2 m from center in Y direction)
